  • FDY 850 Semi Automatic Baler
  • FDY 850 Semi Automatic Baler
  • FDY 850 Semi Automatic Baler

FDY 850 Semi Automatic Baler

    The most popular of the Peaks-eco balers operating in Asian and Europe. The 850 series has an extensive range of designs and configurations. The different models produce bales of between 200 and 400kg, with varying output options to suit actual requirements.

The Peaks eco FDY 850 series of semi and fully automatic horizontal balers are popular across many industries and can deliver outstanding results for your business. Our Semi Automatic Baler Machine/Full Automatic Baler Machine include paper baler machine, plastic baler machine, horizontal baler machine.

The automatic operation of these balers substantially reduces required labour for processing of materials and with the vertical wire tie setup, keeps the footprint compact enabling you to install the baler in many tight locations and in close proximity to the where the material is generated inside your facility, which creates great opportunities for reducing time and handling of moving materials through your facility.

The loading setup options are endless and include all the regular loading options including: hand-load, hydraulic bin lifter, conveyor, air conveyor, mobile equipment as common examples. In addition, we are able to offer both the space saving vertical wire tying option, as well as the traditional horizontal wire the option, which provide opportunities to process just about any product in just about any environment.







FDY 850 Semi Automatic Baler

FDY 850 Semi Automatic Baler

FDY 850 Semi Automatic Baler

A great investment for your business, offering financial, operational and environmental benefits for your business, in operation in Asian and Europe. A few more examples are as follows:

  • Automatic operation

  • Space saving vertical wire tie system

  • Horizontal wire tie system

  • Large hopper and opening

  • Variable bale length to suit your requirements

  • High compaction force producing a dense bale

  • Easy to use controls,

  • Easy access for wire replacement

  • Easily processes a range of materials, including: cardboard, paper, trim, paper offcuts, plastic film and beverage containers

  • Suits a range of different Industries, including: Industry, Manufacturing, Print, Packaging, Retail, Logistics, Distribution, Recycling, Materials Recovery Facilities (MRF’s)

  • Ideal for processing recyclable volumes and fed continuously by either: hand, bin lifter, conveyor or air conveying and separation systems, mobile equipment or a potential combination of these solutions.

FDY 850 Semi Automatic Baler     FDY 850 Semi Automatic Baler     FDY 850 Semi Automatic Baler

Parameters   of 850 semi-automatic waste paper baler machine

1



Main   cylinder



Mode

Φ220

Route

2600mm

Homemade cylinder

Nominal   force

930KN

Amount

1 set

2

Side   plate of mainframe

10#


3

Pressure   of hydraulic system

1500KN


4

Feed   opening size

1100*2000mm


5

Bale   size

1100*850*L(adjustable1500-2000)mm

3 lines

6

Bale   density

500kg/m³


7

Main   engine power

30KW+5.5KW+4.0KW


8

Power   supply specification

25m² soft copper


9

Strapping

No.12 iron wire or golden wire


10

Operation   mode

Manual operation / linkage


11

Cooler

8


12

Production   capacity

6-12 bales per hour


13

Hydraulic pump mode

Plunger pump 250ml/r*1

Gear pump 16ml/r*1

Forward   rotate

14

Fuel   tank capacity

1.6m³


 15

Conveyor

(W)2m*9m
