PLC control，human computer interface and window monitoring，sync action indication with error warning，can set the length of the bale；
Floating gate design，is conducive to the automatic distribution of all the pressure；
Equipped with distributed type shear knife on charging opening, high shear efficiency；
Strapping automatically, Speed up packaging.
Product name | Model 850 fully automatic baling machine |
Modes | Model 850 fully automatic |
Main cylinder | Φ220(cylinder diameter)/2600mm(stroke) |
Bale size | 1100(w)*850(h)mm*length adjustable |
Motor power | 30KW |
Bale density | About 450kg/m3 |
Strapping lines | 3lines |
Operation ways | PLC control，Strapping automatically |
Capacity | About 7-10 bale/h |
Product name | Model 850 semi-automatic baling machine |
Modes | Model 850 semi-automatic |
Main cylinder | Φ220(cylinder diameter)/2600mm(stroke) |
Bale size | 1100(w)*850(h)mm*length adjustable |
Motor power | 30KW |
Bale density | About 450kg/m3 |
Strapping lines | 3lines |
Operation ways | Push button operation, manual binding mode |
Capacity | About 6-9 bale/h |
