Household waste sorting system

    Municipal solid waste (MSW) and household refuse are generally made up of discarded daily consumables. This regular waste is usually placed in a black bag or trash can containing a mixture of wet and dry recyclable materials, organic, inorganic and biodegradable materials. Through the garbage sorting system independently produced by Qunfeng, garbage recycling can be realized, and paper, plastic, metal, glass, organic matter can be effectively reclassified and recycled.

Household waste sorting system

Living garbage after special garbage truck transport to the plant into the enclosed between the discharge, through the photoelectric switch or radar surveillance system, video monitoring, etc according to the site condition automatically open and close doors, then the truck automatic discharge, discharge process automatically open aseptic disinfection device and negative pressure deodorization system, to further the garbage disposal. By the plate feeder and transportation belt conveyor living garbage feeding garbage sorting coarse crusher crusher (level) of the pretreatment system into the hopper, torn bags at the same time the material particle size break below 250 mm, after primary crusher of living garbage by transport belt conveyor to drum sieve, iron remover is set in transport belt, The iron separator separates the iron (magnetic material) contained in the broken household garbage, and the working state of magnetic separation is closed. The roller screen will be more than 80mm (on the screen) and less than 80mm (under the screen) two specifications.


The material on the roller screen (more than 80mm) is conveyed to the air separator, which is separated by the air separator, and the light and heavy substances are screened out. Heavy materials (stone, glass, concrete, etc.) are transferred to designated sites for landfill; Light materials (paper, plastic and other combustible materials) enter the secondary crusher, after crushing, iron (magnetic substances) are separated by iron separator, and the remaining materials are made into garbage derived fuel (RDF fuel).


The material under the roller screen (less than 80mm) is sorted out by the iron separator, and the remaining heavy material (stone, glass, concrete, etc.) is transferred to the designated place for landfill.
