1. After going into the field, the garbage in the vehicle will be unloaded on
the discharge platform, and then sent to the scale plate by hopper.
2. After uniformly distributed, the garbage is sent to the manual sorting
platform by belt conveyor, where the employees will sort and pick the large
objects (quilts, cotton clothes, trunk, branches, long sticks, brick and stone,
bottles, etc.) and toxic waste.
The bag breaker can divide the garbage wrapped in plastic bags for additional
3. Once agreeing by manual, the garbage will be sent into screening system by
belt conveyor for screening treatment. According to the technical requirement,
we set the sieve plate diameter of the cage screening system as 50mm. The
garbage sorting machine can split the garbage into two parts: large than 50mm
and smaller than 50mm. The garbage bigger than 50mm is largely organic thing,
and also the iron objects within this part of organic matter could be selected
out by the hanging magnetic separator, and then is sent into compost workshop
4. The iron materials bigger than 50mm (mainly iron drink cans and iron cans)
could be sorted out by magnetic separation. Afterward the other garbage bigger
than 50mm is sent into winnowing system by belt for end election therapy. The
comprehensive winnowing machine may sort the garbage on the display out and
divide into three parts: the light plastic waste; heavy materials (bricks and
tones, rubber shoes, tiles, glass, etc.); secondary heavy materials (hard
plastic, textiles, rubber goods, wet paper products, etc.).
5. The three kinds of waste will respectively go to various followup devices
equipped with garbage sorting machine for additional processing.
