The Solid Waste Baler is designed to meet the needs of the user, which vary depending on the size and type of material they wish to compact and transport. However, the basic design of a waste baler consists of three main components: the container, the compactor and the power unit. First, the waste is collected in a container. Once filled, the waste is compacted by the compactor into bundles or bales.
Usually, this compaction is followed by a packaging process. Wrapping the waste bales helps to further protect them for future use. It reduces the possibility of problems such as windblown waste, odors, vermin or damage caused by dislodged waste by protecting the bundle from water damage and ensuring it is contained.
Solid Waste Balers can often collect the smallest pieces or debris for baling, such as unsalable textile fabric scraps or scrap metal fragments. In addition, they are an economical option for waste collection and transportation, whether for disposal, recycling or sale to another company for reuse.
An indirect benefit of waste balers is the revenue generated by this efficient collection and redistribution system. Depending on the size of your business and the extent of your compaction needs, you may consider purchasing a Waste Baler to economically dispose of and redistribute your surplus materials and waste.
Planning to purchase a Waste Baler?
When considering a waste baler, check these things.
"What do you plan to bale?"
"What is the maximum size of most materials?"
"How much material will be baled during the busiest times?"
"How will the baler be used?"
"How will the bales be stored?"
"What is the delivery method?"
"Is there a maximum weight for the means of transport?"
"Will the baling be manual or automatic?"
Consider these questions or ask us directly if you don't understand anything and our professionals will give the best advice!
Qunfeng Solid Waste Baler
Qunfeng plants and balers for waste treatment were designed to sort municipal solid waste (MSW), unsorted solid waste with organic material, industrial waste, refuse derived fuel.
Our machines efficiently recover and enhance the materials contained in the waste. This applies to PET, HDPE, cardboard, paper, aluminium. In a recovery process, these materials are not destroyed, but collected and processed to generate new raw materials: “secondary raw materials”.
Waste baling provides advantages in terms of logistics, of landfill lifetime and environmental safety.
Our balers can also be equipped with wrapping machines that reduce odor and leachate spilling, increasing environmental safety of landfills.
Baler is to reduce the volume of recyclable materials and produce compressed bales by using the powerful force of hydraulic cylinder. Baler is popularly used for continuous compression of wastes with recyclable value such as paper, cardboard and plastics; drum baler used for continuous compression of PET bottles, paper and cardboard. Automatic control by PLC and tight wire coupling can help produce tightly compressed bales and provide users with the convenient and safe operation. The compressed bales allow the users to have more storage space and transportation highly economical. Baler is typically installed on the final discharge section of MSW system.
Industrial recycling solid waste balers and garbage compactors list
| Model | Hydraulic system pressure | Host power | Bundle size | Bundle density | Production capacity | Features |
| FDY 850 Semi Automatic Baler Machine | 1500KN | 30KW+5.5KW+4.0KW | 1100*850*L(adjustable:1500-2000)mm | 500kg/m³ | 6-12 bales/hour | Automatic operation
Space-saving vertical tying system
Horizontal taping system
Large hoppers and openings
Variable bale lengths to meet your requirements
High pressure strength produces dense bales
Easy to use controls
Easy to change wires |
| FDY 850 Full Automatic Baler Machine | 30KW+5.5KW+5.5KW | 7-10 bales/hour |
| FDY 1250 A Semi Automatic Baler Machine | 1600KN | 37KW-4+5.5KW+4.0KW | 1100*1250*L(adjustable:1500-2000)mm | 450kg/m³ | 7-10 bales/hour | Automatic operation
Horizontal tie system
Oversized hopper and feed opening
Variable bale length
High pressure strength
Easy to use touch screen controls
150 and 200 ton pressure options
10 to 25 tons per hour |
| FDY 1250 C Semi Automatic Baler Machine (Lengthen type) | 45KW+5.5KW+4.0KW | 500kg/m³ | 7-12 bales/hour |
| FDY 1250 D One Motor With Two Pump Waste Paper Baler Machine | 9-16 bales/hour |
| FDY 1250 E Semi-Automatic With Door Baler Machine | 55KW+5.5KW+4.0KW | 5-10 bales/hour | Semi-automatic operation
Manual tie down
Enclosed door for enhanced compaction
Large hopper and openings
High-pressure strength produces dense bales
Easy-to-use controls |
| FDY 1250 F Double Motor With Two Pump Waste Paper Baler Machine (Lengthen Type) | 37KW+5.5KW+4.0KW+45KW | 18-25 bales/hour | Automatic operation
Horizontal tie system
Oversized hopper and feed opening
Variable bale length
High pressure strength
Easy to use touch screen controls
200 and 300 ton pressure options
20 to 40 tons per hour |
Benefit:
1. Powerful compression by hydraulic motor
2. Continuous compressing
3. Hydraulic door mode for the safety
4. Easy to maintain compression ram
5. Automatic wire connection
6. Easy operation with PLC
